Single-sided with a Hole Square Milling Inserts | High-Precision Adapt to Hitachi Insert for CNC Machining

Single-sided with a hole square milling insert: Built for Demanding CNC Applications

Single-sided with a Hole Square Milling Inserts - Single-sided with a hole square milling insert
  • Single-sided with a Hole Square Milling Inserts - Single-sided with a hole square milling insert
  • Single-sided with a hole square milling insert manufacturer.

Single-sided with a Hole Square Milling Inserts

Adapt to Hitachi Insert

Square milling inserts are cutting tools used for milling. The insert is square in shape. Generally, the ISO code starts with "S" or "L". It is single-sided milling. The 45-degree angle part is the cutting edge. There are also specifications for whether the surface is brighter after processing. The middle screw hole improves the fixing strength and can increase the cutting depth of processing. AL is a plate type for aluminum.

Milling inserts have multiple cutting edges. After processing for a period of time, they can be rotated to another corner and the insert can be replaced to extend the service life of the insert. The processing conditions are high cutting depth and medium to low speed to achieve high torque removal effect. The processed surface is mostly flat and slightly smooth cutting surface with medium to high roughness. It is also suitable for processing many different materials, including metals, plastics, composite materials, etc. Generally speaking, this type of blade has higher rigidity and stability to ensure cutting accuracy.

SE Type
  • GW1370-1, SEGW1204ADTR-MO
  • GW859, SEMW1204ADTR-MO
  • GW859B-A, SEMT1204ADTR
  • GW859B, SEMT1204-B
  • GW1522A, SDGT09T308
  • GW1802, SEHT13T3-AL
  • GW1643, SEMT13T3ADR-SWU
  • GW1643-NC, SEHT13T3-AL
Specification
SE high speed feed rate inserts
Ordering CodeInsert ISO CodeDimension
DSFrθ
GW1370-1SEGW1204ADTR-MO12.704.76--20°
GW859SEMW1204ADTR-MO12.704.76--20°
GW859B-ASEMT1204ADTR12.704.76--20°
GW859BSEMT1204-B12.704.76--20°
GW1802SEHT13T3-AL13.403.972.100.8020°
GW1643SEMT13T3ADR-SWU13.403.971.800.8020°
GW1643-NCSEHT13T3-AL13.403.972.100.8020°
Seeking Distributors for Partnership
  • Technical support
  • Education and training
  • High-cost performance
  • Flexible delivery time
  • Complete supply chain

Single-sided with a Hole Square Milling Inserts | Guass Carbide Inserts – Engineered in Taiwan for Precision, Strength & Value

Enhance your machining accuracy and efficiency with high-performance Single-sided with a Hole Square Milling Inserts engineered by Guass. Designed to handle challenging materials and high-speed operations, our inserts deliver consistent results across turning, milling, and drilling applications.

Whether you're working with hardened steel, stainless alloys, or composites, our ISO-certified solutions are trusted by manufacturers in aerospace, automotive, electronics, and plastic injection molding industries. Each insert is crafted for longevity, excellent chip control, and minimal downtime—making your CNC process faster and more cost-effective.

With over 15 years of expertise in tungsten carbide sintering and tool innovation, Guass continues to set the standard for precision tooling. Explore our full selection of carbide inserts built for maximum durability and performance.
